Product Details
Place of Origin: China
Brand Name: Huajing
Model Number: GJS-M5/JFT-BS
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: 19.9-28.6USD/PC
Delivery Time: 1-4weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union
|
Model.:
|
GJS-M5/JFT-BS
|
Material:
|
MPP
|
Size:
|
Φ230×320mm
|
Cable Port:
|
5
|
Capacity:
|
144 Cores (single Core)
|
Splice Tray Capacity:
|
16 Cores
|
Sealing Type:
|
Mechanical Seal＆silicon Rubber
|
|
Model.:
|
GJS-M5/JFT-BS
|
|
Material:
|
MPP
|
|
Size:
|
Φ230×320mm
|
|
Cable Port:
|
5
|
|
Capacity:
|
144 Cores (single Core)
|
|
Splice Tray Capacity:
|
16 Cores
|
|
Sealing Type:
|
Mechanical Seal＆silicon Rubber
|
Application:
This product is used for optical splitting or direct connection during optical fiber transmission process, and provides joint connection protection.
Feature:
Technical Index:
Specification:
| Parameter | Packing Detail | ||
| Size(mm): W*D*H(mm) | Φ230×320 | Carton size(mm) | 490×420×720/8pcs |
| Weight(Kg) | 3.05 | CBM(m³) | 0.148 |
| Cable port | 5 | Gross weight(Kg) | 25.8 |
| Cable diameter(mm) | Φ7-Φ18 | Others | |
| Tray capacity | 16(single core) | ||
| Max tray number | 9 | ||
| Core capacity | 144 cores (single core) | Installation | wall mounting(optional) |
| Sealing type | Mechanical seal＆silicon rubber | pole mounting(standard) | |
